DE-CORING HAMMER

J B Engineering and Automation is the Authorised Distributor and After Sales Service provider for OMLER PNEUMATICS HAMMERS ITALY make for India.

O.M.LER s.r.l. manufactures in cooperation with the sister company O.M.LER 2000 decoring hammers for foundry in different models depending on the kind of casting to decore.

The hammers remove the sand core from cast iron, aluminium and steel castings of engine parts and from castings produced using the investment casting process.

Product Features:

Light weight
Forefront
Low friction
Sensor inside the jacket with fixed connector
High performances
Made with new materials

MODELS	RVC70	RVC70-MBL	RVC70-MBR
FREQUENCY (4 BAR / 5 BAR / 6 BAR)	18,4/19/20,5 HZ	19/ 20,5/21,5 HZ	20,5/23/ 25 HZ
AIR CONSUMPTION (4 BAR / 5 BAR / 6 BAR)	840/905/1040 L/min	846/932/942 L/min	814/922/928 L/min
AIR INLET COUPLING	3/4 GAS	3/4 GAS	3/4 GAS
HAMMER WEIGHT WITHOUT BEATER	24 kg	24 kg	24 kg
RECOMMENDED BEATING DISTANCE	70 mm	70 mm	70 mm
MAXIMUM BEATING DISTANCE	120 mm	120 mm	120 mm

Avaialbe in different models, depending on the kind of casting to be decored ORDER NOW
